Mastercam Design SolutionsMastercam Design is a computer-aided design solution that simplifies the creation of even the most complex parts with a robust suite of CAD tools. Design is included with Mastercam’s suite of CAM solutions. It is also available as a standalone product. From fixing flaws in an imported model, to creating fixtures for work holding on a machine-and so much more, this powerful CAD engine includes modeling and prep tools for CAM programmers to get parts on and off machines quickly.
|
A notable advantage of Mastercam's integrated CAD for CAM is the ability to import files from virtually any computer-aided design source. Mastercam includes a large selection of CAD model importers, so no matter where a model was created, you can import and modify as needed for your machining purposes.
- Mastercam can read CAD files from ASCII, CADL, DWG, DXF, EPS, IGES, Inventor (IPT, IDW, IAM), KeyCreator Files (CKD), Parasolids, Rhino 3DM, SOLIDWORKS (SLDPRT, SLDASM, SLDDRW), SAT (ACIS solids), Solid Edge (PAR & PSM), SpaceClaim Files (SCDOC), STEP, STL, and VDA.
- Specialty data translators are available to read CAD files from UG/NX, CoroPlus®, Creo, and CATIA™.
- Full 3D CAD modeling.
- Import, create, and manipulate wireframe, surfaces, STL, and solids data.
- Mastercam Art makes it possible to work with files including JPG, TIFF, and raster-based images—and create a 3D relief based on user preference.
System Requirements
Minimum | Recommended |
OS |
Windows 10 or Windows 11 64-bit Professional
|
Windows 10 (version 20H2 or later) 64-bit Professional
|
---|---|---|
Processor |
Intel® or AMD 64-bit processor, 2.4 GHz or faster
|
Intel i7 or Xeon® E3, Kaby Lake or later, 3.2GHz or faster
|
Memory |
8 GB
|
32 GB
|
Video |
OpenGL 3.2 and OpenCL 1.2 support with 1 GB memory. No onboard graphics.
|
NVIDIA Quadro® or AMD FirePro™ / Radeon Pro card with 4 GB (or higher) dedicated memory.
|
Monitor |
1920 * 1080 resolution
|
1920 * 1080 resolution, dual monitors
|
Storage |
Solid State Drive (SSD) with at least 20 GB free and a USB 2.0 reader (for installation media)
|
NVMe Drive with at least 20GB free
|
3D Mouse |
|
3Dconnexion 3D mouse
|
Connection to Internet and email is recommended for installation, support, and updates.
